Battery Capacity
171/256/385 Kwh

Charging Time
1 Hours

Power
470 HP

GVW
45000 Kg
Ad
Ad
Ground Clearanc...
265
Cargo Box Dimen...
18 CUM
Width (mm)
2800
Gross Vehicle W...
45000
Length (mm)
8275
Height (mm)
3650
Wheelbase (mm)
4300
Battery Capacit...
171/256/385
Kerb Weight (Kg...
NA
Payload (Kg)
NA
Max Speed (Km/h...
40
Driving Range (...
NA
Charging Time (...
1
Battery Type
Li-on
Gradeability (%...
30
Power Steering
Yes
Steering
Hydraulic Integral Power Steering
Warranty
NA
Parking Brake
Pneumatic Hand Control Valve
Front Axle
Steerable, 9.5T heavy duty I Beam
Rear Axle
37T Tandem, Hub Reduction cast axle
Body Type
Rock Body
Cabin Type
Sleeper Cabin
Chassis Type
Ladder construction, C-channel with full flitch reinfor...
Tiltable Cabin
Yes
Suspension - Fr...
1x9.5 T Parabolic Leaf Spring with Shock Absorber
Suspension - Re...
37 T Inverted Semi Elliptical Bogie
Turning Radius ...
8250
Fuel Type
Electric
Power (HP)
470
Torque (Nm)
2800
Emission Norm
Zero Emission
Transmission Ty...
7 Speed EMT without Clutch
Motor Type
PMSM
Gearbox
7 Speed EMT
Adjustable Driv...
Yes
Seat Belts
Yes
Seat Type
Standard Seats
Tiltable Steeri...
Yes
Seating Capacit...
Driver + 1 Passenger
Hill Hold
Yes
Brakes
Dual line air brakes with ABS
ABS
Yes
Number of Tyres
10
Front Tyre Size
12x20 Mining Tyre
Rear Tyre Size
12x20 Mining Tyre
|  |  |  |  |  |  |  |
| Propel 470 MEV | Tata Ace EV | Tata Ace EV 1000 | Eicher Pro 2055 EV | Mahindra ZEO | Euler Turbo EV 1000 | Switch Mobility IeV3 |
| Price Coming Soon | ₹ 10.20 Lakh | ₹ 11.27 Lakh | ₹ 27.00 Lakh | ₹ 7.78 Lakh | ₹ 6.00 Lakh | ₹ 12.32 Lakh |
| Fuel Type | ||||||
| Electric | Electric | Electric | Electric | Electric | Electric | Electric |
| Battery Capacity (kwh) | ||||||
| 171/256/385 | 21.3 | 21.3 | 64.4 | 18.4 | 15.36 | 25.6 |
| Charging Time (hours) | ||||||
| 1 | Fast charging in 105 mins, Home Charging in 7 Hours | 7 | 8-10 | AC Charging (Onboard Regular (3.3 KW O/P))- 6 hrs, AC Charging (Wall Mounted (6.6 KW O/P))- 3.13 hrs &, DC Charging - 1.08 hrs | 4-4.5 | DC charging-Fast Charging 55 mins (0 to 80%), AC charger (32A)-3 hours 30 mins, AC charger (15A)-8 hours 15 mins |
| Power (HP) | ||||||
| 470 | 36 | 36 | 122 | 40 | 20 | 53 |
| GVW (kg) | ||||||
| 45000 | 1840 | 2120 | 5450 | 1675 | 2000 | 2590 |
| Payload (kg) | ||||||
| NA | 600 | 1000 | 2209 | 765 | 1000 | 1250 (FSD) |
| Currently Viewing | 470 MEV vs Ace EV | 470 MEV vs Ace EV 1000 | 470 MEV vs Pro 2055 EV | 470 MEV vs ZEO | 470 MEV vs Turbo EV 1000 | 470 MEV vs IeV3 |
