BULL HD 76 4WD Backhoe Loader

Model

KILOSKAR 4R1040 TC BS

Compliant

BS-III

Gross Power

76 HP

Displacement

N/A

Maximum Torque

300 NM

Air Intake Type

N/A

Dump Angle

45 Deg.

Dump Height

2930 MM

Max Pay Load

1800 kgf

Reach At Ground

1470 MM

Hinge Pin Height

N/A

Load Over Height

3390 MM

Rollback At Ground

50 Deg.

Bucket Capacity Std

1 Cum

Bucket Breakout Force

N/A

Hinge Pin Forward Reach

420 MM

Max Reach At Full Height

1420 MM

Maximum Lifting Capacity

N/A

Loader Arm Breakout Force

5251 kgf

Below Ground Level Dig Depth

80 MM

Max Reach At Full Height Bucket Dumped

1100

Type

Power Steering

System Pressure

N/A

Unit Displacement

N/A

Turning Circle Diameter Outside Bucket

N/A

Turning Circle Diameter Outside Bucket Not Braked

N/A

Max Dig Depth

4600 MM

Bucket Capacity

1 Cum

Bucket Rotation

188 deg.

Max Lift Capacity

1800 Kg

Safe Working Load

N/A

Max Working Height

N/A

Dipper Configuration

N/A

Max Load Over Height

3390 MM

Bucket Breakout Force

N/A

Dipper Tear Out Force

N/A

Bucket Capacity Backhoe

0.2

Reach Ground Level To Swing Center

N/A

Reach At Full Height To Slew Center

N/A

Reach Ground Level To Rear Wheel Center

6810 MM

Wheelbase

N/A

Track Width Rear

N/A

Transport Length

N/A

Track Width Front

N/A

Width Over Bucket

N/A

Max Operating Weight

7850

Width Over Stabilizer

N/A

Height To Top Of Cabin

N/A

Minimum Ground Clearance

N/A

Overall Transport Height

N/A

Pump Flow

113 lpm

Pump Type

N/A

System Type

N/A

System Relief Pressure

N/A

Coolant

17 L

Fuel Tank

115/150 L

Rear Axle

17 L

Engine Oil

12 L

Hydraulic Oil System

120 Ltr

Hydraulic Oil Replacement

N/A

Transmission Oil Capacitysystem

19.5 L

Standard Tyre Rear

16.9x28 - 12 PR

Standard Tyre Front

12.5/80-18-12 PR

Hd Tyre Rear Optional

N/A

Parking

N/A

Service

N/A

Rear

N/A

Front

N/A

Front Axle Oscillation

N/A
