Tata Hitachi ZW 550

Bore

159 mm

Model

Cummins QSK19

Stroke

159 mm

Max Power

483 Hp

Displacementl

18.87 L

Max Torque N M

1125 Nm

Operating Weight

45960 kg

Tipping Load Full Turn

24750

Exterior Sound Power Db

N/A

Operator Sound Power Db

N/A

Wheelbase

4150 MM

B Pin Height

5040 MM

Bucket Capacity

6.0 - 10.0 m3

Rack Back Carry

N/A

Ground Clearance

545

Rack Back Ground

N/A

Lift Arm Clearance

N/A

Height To Top Of Hood

N/A

Height To Top Of Rops

4170 mm

Rack Back Maximum Lift

N/A

Height To Top Of Exhaust Pipe

N/A

Center Line Of Rear Axle To Hitch

N/A

Center Line Of Rear Axle To Edge Of Counterweight

N/A

Implement Maximum Flow

N/A

Steering System Pump Type

Load-sensing hydraulic steering (fixed displacement gear pump, shared circuit); Articulated Frame Steering, ±40°

Implement Maximum Operating Pressure

N/A

Crankcase

61 L

Fuel Tank

660 L

Transmission

90 L

Cooling System

155 L

Hydraulic Tank

225 L

Differentials And Final Drives Rear

360 L

Differentials And Final Drives Front

360 L
