Tata Hitachi Zaxis 80 Excavator

Bore

94 MM

Model

MHI S4S

Power

55 HP

Stroke

120 MM

Displacement

3.331 L

Power Iso 14396

0

Net Power Iso 9249

55 hp

Weights Engine Oil

10 L

Weights Final Drive

N/A

Weights Swing Drive

N/A

Weights Cooling System

N/A

Weights Hydraulic Tank

60 L

Weights Operating Weight

7650 Kg

Weights Fuel Tank Capacity

135.0 L

Weights Service Refill Capacities

N/A

Weights Hydraulic System Including Tank

100 L

Boom

N/A

Stick

N/A

Bucket

N/A

Track Gauge

1700 MM

Track Length

N/A

Handrail Height

N/A

Shipping Length

6080 MM

Transport Width

N/A

Ground Clearance

360

Tail Swing Radius

1720 MM

Counterweight Clearance

760 MM

Shipping Height Top Of Cab

2600 MM

Length To Center Of Rollers

N/A

Maximum Pressure Swing

N/A

Maximum Pressure Travel

N/A

Main System Maximum Flow

20 Lpm

Maximum Pressure Equipment

N/A

Hydraulic System

100 L

Boom

N/A

Stick

N/A

Bucket Capacity

0.2

Lifting Capacity

N/A

Maximum Digging Depth

4170 MM

Maximum Cutting Height

7150 MM

Maximum Loading Height

N/A

Minimum Loading Height

N/A

Stick Digging Force Iso

N/A

Bucket Digging Force Iso

N/A

Maximum Reach At Ground Level

N/A

Maximum Vertical Wall Digging Depth

4280 MM

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

N/A
