Tata Hitachi EX 200LC Tunnel Excavator

Bore

102 mm

Model

Cummins 6BT5.9C

Power

133 HP

Stroke

120 mm

Displacement

5.9 L

Power Iso 14396

133 HP (99.2 kW)

Net Power Iso 9249

133 PS (130 HP)

Weights Engine Oil

14 L

Weights Final Drive

Not publicly disclosed by Tata Hitachi for any EX-series model

Weights Swing Drive

6.7 L

Weights Cooling System

25 L (platform standard)

Weights Hydraulic Tank

129 L

Weights Operating Weight

19600 Kg

Weights Fuel Tank Capacity

310 L

Weights Service Refill Capacities

35

Weights Hydraulic System Including Tank

220 L

Boom

3600 mm (est., shortened tunnel boom)

Stick

1600 mm (est., shortened tunnel arm)

Bucket

600-800 mm width (est., 0.8 m³ bucket)

Track Gauge

2390 mm

Track Length

3660 mm

Handrail Height

1100 mm (est., standard cab height)

Shipping Length

8200 mm (est., shortened from 9720 mm standard due to short boom)

Transport Width

2990 mm

Ground Clearance

435

Tail Swing Radius

2400 mm (est., reduced per manufacturer description vs. 2785 mm standard)

Counterweight Clearance

1050 mm (platform standard)

Shipping Height Top Of Cab

2850 mm

Length To Center Of Rollers

4460 mm

Maximum Pressure Swing

26.9 MPa

Maximum Pressure Travel

34.3 MPa

Main System Maximum Flow

2 x 118 Lpm (est. correction of source's likely-truncated '2 Lpm')

Maximum Pressure Equipment

27.9 MPa

Hydraulic System

2 variable-displacement axial piston pumps + 1 gear pump (Hitachi OHS)

Boom

Short boom, tunnel-optimized configuration

Stick

Repositioned arm cylinder for confined tunnel clearance

Bucket Capacity

0.8

Lifting Capacity

N/A - not applicable, excavator not rated for crane-lift duty

Maximum Digging Depth

3280 mm

Maximum Cutting Height

9160 mm

Maximum Loading Height

5500 mm (est., reduced due to short boom)

Minimum Loading Height

2200 mm (est.)

Stick Digging Force Iso

114.7 kN (platform standard, EX200/210 series)

Bucket Digging Force Iso

120.1 kN (platform standard)

Maximum Reach At Ground Level

7200 mm (est., reduced due to short boom/arm)

Maximum Vertical Wall Digging Depth

2725 mm

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

2650 mm (est.)
