Escorts F23

Model

VECV make E494, CEV Stage V diesel engine, high pressure common rail system (HPCR) technology, turbo charged water cooled ECU control engine management system developing 74 kW/101 HP @2200 RPM or equivalent engine

Clutch

Single, dry type friction clutch plate (self adjusting)

Gearbox

10 Forward & 2 Reverse

Compliant

CEV Stage V

Gross Power

101 HP

Clutch Actuation

Pneumatic assisted hydraulic clutch

Transmission Type

Engine is coupled with synchromesh transmission gear box and auxiliary gear box with high/low & 2WD/4WD mode selector

Articulation

40 Degree

Steering Type

Full power control with twin hydraulic double acting rams 40° articulation on either side

Features

LED Work Lamp, Cluster, HPCR System, EQU EMS System, Hydraulic Clutch, Telematics, Diesel Particulate Filter (DPF), Rocker Switches, Ignition On/Off, Electronic Accelerator Pedal

Optional Safety Features

Outrigger Home Position Sensing System (OHPSS), Use Of 1st & Reverse Gear For Craning Operation: Speed ≤ 2 km/h Audio Alarm Will Blow, Mandatory Outrigger Mechanism For Erection Jobs, Retraction Of Forward Movement In Engaged Outrigger Condition, Safe Mode Operation (No Bypassing Allowed), Lateral & Longitudinal Angle System, Anti-Toppling System, Human Proximity Sensor, Integration Of SLI With Telematics

Track

Front Track- 1960 MM, Rear Track- 1960 MM

Width

2700 MM

Height

3300 MM

Lenght

10900 MM

Wheelbase

4880 MM

Rated Capacity

23T at - 1.5M Radius, 900Kg at- 16.6 M Radius, Max Height- 22300 MM

Turning Radius

8250 MM

Total Operating Weight

Travel- 19360 Kg, Work- 21950 Kg

Pump

Tandem hydraulic vane pump

Control Valve

Main control valve 3 spool double acting with a built-in relief & auxiliary valves

Drag Winch Control Valve

Single spool double acting

Outtrigger Control Valve

2 spool double acting

Fuel Tank

270 Ltr.

Hydraulic Tank

185 Ltr

Rear Tyre

12 x 24 - 20 PLY

Front Tyre

12 x 24 - 20 PLY

Wheel Drive

4 WD

Parking Brakes

Air operated, spring actuated, fail safe brakes on front and rear wheels

Service Brakes

Fully air operated brakes on front and rear wheels

Max Speed

40 Km/h

Creep Speed

1.3 Km/h

Gradeability

40% Unladen

Telescoping

4 parts boom, 3 parts hydraulically powered & fully synchronized, 4th part power extended & manually pinned for safety

Luffing Range

-3° to +65°

Mechanism Hoist

15T hydraulically operated with 6 falls Built-in safety brakes

Rear

Mounted with semi-elliptical springs, hub reduction drive axle

Front

Heavy duty rigidly mounted hub reduction drive axle
