Volvo EC480DL Excavator

Bore

131 MM

Model

D13F

Power

288 HP

Stroke

158 MM

Displacement

N/A

Power Iso 14396

0

Net Power Iso 9249

288 hp

Weights Engine Oil

42 L

Weights Final Drive

N/A

Weights Swing Drive

N/A

Weights Cooling System

60 L

Weights Hydraulic Tank

270 L

Weights Operating Weight

53100 Kg

Weights Fuel Tank Capacity

685 L

Weights Service Refill Capacities

N/A

Weights Hydraulic System Including Tank

520 L

Maximum Pressure Swing

N/A

Maximum Pressure Travel

N/A

Main System Maximum Flow

2 Lpm

Maximum Pressure Equipment

N/A

Hydraulic System

520 L

Boom

N/A

Stick

N/A

Bucket Capacity

3.8

Lifting Capacity

N/A

Maximum Digging Depth

6580 MM

Maximum Cutting Height

N/A

Maximum Loading Height

N/A

Minimum Loading Height

N/A

Stick Digging Force Iso

N/A

Bucket Digging Force Iso

N/A

Maximum Reach At Ground Level

N/A

Maximum Vertical Wall Digging Depth

5900

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

N/A

Cylinder Bore

N/A

Cylinder Store

N/A
