Volvo EC210D Excavator

Bore

108 MM

Model

D5E

Power

156 HP

Stroke

130 MM

Displacement

N/A

Power Iso 14396

0

Net Power Iso 9249

156 hp

Weights Engine Oil

17 L

Weights Final Drive

N/A

Weights Swing Drive

N/A

Weights Cooling System

15 L

Weights Hydraulic Tank

160

Weights Operating Weight

22800 Kg

Weights Fuel Tank Capacity

375 L

Weights Service Refill Capacities

N/A

Weights Hydraulic System Including Tank

300

Boom

N/A

Stick

N/A

Bucket

N/A

Track Gauge

2200 MM

Track Length

4160 MM

Handrail Height

N/A

Shipping Length

N/A

Transport Width

N/A

Ground Clearance

460

Tail Swing Radius

2850 mm

Counterweight Clearance

1025

Shipping Height Top Of Cab

2930 MM

Length To Center Of Rollers

N/A

Maximum Pressure Swing

N/A

Maximum Pressure Travel

N/A

Main System Maximum Flow

N/A

Maximum Pressure Equipment

N/A

Hydraulic System

N/A

Boom

N/A

Stick

N/A

Bucket Capacity

0.52

Lifting Capacity

7240 Kg

Maximum Digging Depth

6730 MM

Maximum Cutting Height

9220 MM

Maximum Loading Height

N/A

Minimum Loading Height

N/A

Stick Digging Force Iso

N/A

Bucket Digging Force Iso

N/A

Maximum Reach At Ground Level

9380 MM

Maximum Vertical Wall Digging Depth

5620

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

6100 MM
