Voltas DVX 806

Rating

100 HP

Rated Rpm

2300

Make Model

N/A

No Of Cylinders

N/A

Rated Torque Kgm Rpm

37 @ 1500

Height

N/A

Fork L W T

65 x 150 x 1200 MM

Aisle Width

N/A

Lift Height

N/A

Overall Width

2325 MM

Std Free Lift

N/A

Front Overhang

715 MM

Turning Radius

4200 MM

Tilt Angle Forward

N/A

Fork Spread Maximum

1800 MM

Fork Spread Minimum

120 MM

Tilt Angle Backward

N/A

Ground Clearance Fork

N/A

Ground Clearance Mast

315 MM

Overhead Guard Height

2550

Fork Carriage Iso Class

BAR

Length To Face Of Forks

4550 MM

Tyres Size Rear

7.5 X 20-12 PR

Tyres Size Front

10.00 X 20-16 PR

Tyres Wheel Base

3000 MM

Parking Brakes Type

Pneumatic

Service Brakes Type

Pneumatic
