Tata Hitachi EH 3500AC 3

Bore

159 MM

Type

4 Cycle Diesel w/ MCR fuel system

Model

Cummins QSKTA50-CE (Standard) / MTU 12V4000 C21 (Optional)

Stroke

159 MM

Max Power

1491-1510 KW (2000-2025 HP)

Net Power

1398 KW (1874 HP) @1900 RPM

Aspiration

2 stage Turbocharged & Low Temperature Aftercooled

Gross Power

1491 KW (2000 HP) @1900 RPM

Displacementl

50.3 L

Type Optional

4 Cycle Diesel w/ DDEC

Max Torque N M

7871 NM (803 KGF.M) @1500 RPM

Model Optional

MTU 12V4000 C21

No Of Cylinders

16

Starting System

24 Volt Electric

Net Power Optional

1417 KW (1900 HP) @1900 RPM

Max Torque Optional

8199 NM (836 KGF.M) @1500 RPM

Bore Stroke Optional

165 x 190 MM

Gross Power Optional

1510 KW (2025 HP) @1900 RPM

Displacementl Optional

48.8 L

Emission Certification

U.S. EPA Tier 2

No Of Cylinders Optional

12

Nominal Payload

181 Tonnes (with 37.00R57 tires) / 178 Tonnes (with 40.00R57 tires)

Operating Weight

322000

Distribution Empty

48% Front / 52% Rear

Net Machine Weight

141000 KG (with 37.00R57 tires) / 146000 KG (with 40.00R57 tires)

Distribution Loaded

33% Front / 67% Rear

Tipping Load Full Turn

N/A

Exterior Sound Power Db

N/A

Operator Sound Power Db

N/A

Operating Weight Optional Tires

324000

Turning Diameter

29.3 M (ISO 7457)

Hydraulic Cylinder Type

Two (2) Hitachi three-stage, double-acting cylinders

Steering System Pump Type

Closed-center, full time hydrostatic power steering, variable displacement piston pump

Crankcase

200 L (Cummins) / 190 L (MTU)

Fuel Tank

2040 L (Standard) / 3690 L (Optional)

Cooling System

531 L (Cummins) / 543 L (MTU)

Hydraulic Tank

750 L

Front Wheels Lr

17 L

Main Accumulator

70 L

Windshield Washer

20 L

Planetary Drives Lr

218 L

Rear Axle

Dry Disc, 109 CM diameter (2 discs/axle, 3 calipers/disc)

Front Axle

Dry Disc, 121.7 CM diameter (2 discs/axle, 3 calipers/disc)

System Standard

ISO 3450 (SAE J1473) compliant

Max Dynamic Braking

2800 KW (Standard)
