Sany STG170C-10
Ad
Features
Net Power
173 HP (≈129 kW)
Turning Radius
7.3–7.5 m (min. turning radius, sources vary slightly)
Working Weight
14,500–14,700 kg (operating weight; sources vary slightly)
Length Of Machine
8,580 mm
Top Forward Speed
36 km/h (6-speed: 5/7/12/18/26/36 km/h)
Top Reverse Speed
26 km/h (3-speed: 5/12/26 km/h)
Sany STG170C-10 Specifications
Key Specification
Net Power
173 HP (≈129 kW)
Turning Radius
7.3–7.5 m (min. turning radius, sources vary slightly)
Working Weight
14,500–14,700 kg (operating weight; sources vary slightly)
Length Of Machine
8,580 mm
Top Forward Speed
36 km/h (6-speed: 5/7/12/18/26/36 km/h)
Top Reverse Speed
26 km/h (3-speed: 5/12/26 km/h)
Net Power
173 HP (≈129 kW)
Turning Radius
7.3–7.5 m (min. turning radius, sources vary slightly)
Working Weight
14,500–14,700 kg (operating weight; sources vary slightly)
View More
Engine
Rpm
Max torque rated at 1,300 rpm; governed/rated engine speed not publicly specified
Bore
Not publicly specified
Model
Cummins QSB6.7 (CEV Stage IV)
Emissions
CEV Stage IV (one source references a CEV Stage V variant — verify per unit/model year)
Net Power
173 HP (≈129 kW)
Max Torque
880 Nm @ 1,300 rpm
Displacement
≈6.7 L (Cummins QSB6.7 series)
No Of Cylinders
6 (standard for Cummins QSB6.7 series; not explicitly confirmed for this model)
Derating Altitude
Not publicly specified
Rpm
Max torque rated at 1,300 rpm; governed/rated engine speed not publicly specified
Bore
Not publicly specified
Model
Cummins QSB6.7 (CEV Stage IV)
View More
Dimensions
Width
Not publicly specified
Max Height
Not publicly specified
Length Of Machine
8,580 mm
Width
Not publicly specified
Max Height
Not publicly specified
Length Of Machine
8,580 mm
View More
Moldboard
Height
Not publicly specified
Thickness
Not publicly specified
Arc Radius
Not publicly specified
Blade Width
Not publicly specified
End Bit Width
Not publicly specified
Throat Clearance
Not publicly specified
End Bit Thickness
Not publicly specified
Cutting Edge Width
3,660 mm (12 ft blade/moldboard length)
Cutting Edge Thickness
Not publicly specified
Height
Not publicly specified
Thickness
Not publicly specified
Arc Radius
Not publicly specified
View More
Blade Range
Max Depth Of Cut
630 mm
Max Lift Above Ground
480 mm
Blade Tip Range Forward
Not publicly specified
Max Shoulder Reach Left
Not publicly specified
Blade Tip Range Backward
Not publicly specified
Circle Center Shift Left
Not publicly specified
Max Shoulder Reach Right
Not publicly specified
Circle Center Shift Right
Not publicly specified
Moldboard Side Shift Left
Not publicly specified
Moldboard Side Shift Right
Not publicly specified
Max Depth Of Cut
630 mm
Max Lift Above Ground
480 mm
Blade Tip Range Forward
Not publicly specified
View More
Service Capacities
Fuel Tank
350 L
Circle Drive
Not publicly specified
Cooling System
Not publicly specified
Engine Crankcase
Not publicly specified
Hydraulic System
Not publicly specified
Transmission And Differential
ZF Tiptronic electronically-controlled powershift transmission (fluid capacity not publicly specified)
Fuel Tank
350 L
Circle Drive
Not publicly specified
Cooling System
Not publicly specified
View More
