LiuGong 926E XDLC

Engine Power

188 hp @ 2,050 rpm (rated)

Bucket Capacity

1.5 m3 GP / 1.35 m3 HD

Operating Weight

26,500 kg

Make

Cummins

Type

6-cylinder diesel, turbocharged; displacement 6.7 L

Model

QSB7

Power

188 hp (140.1 kW) @ 2,050 rpm

Batteries

N/A - diesel machine; 24 V electrical system

Max Torque

658 Nm @ 1,300 rpm (LiuGong India); Motorbazee lists 800 Nm @ 1,200 rpm

Weights Weight

26,500 kg

Weights Engine Oil

25 L

Weights Final Drive

3.5 L per side (3.5 L x 2, travel device)

Weights Swing Drive

4.4 L

Weights Hydraulic Tank

210 L

Weights Operating Weight

26,500 kg

Weights Service Refill Capacities

Fuel tank 540 L; cooling system 30 L; engine oil 25 L; hydraulic reservoir 210 L; swing drive 4.4 L; travel device 3.5 L x 2

Weights Hydraulic System Including Tank

Not publicly specified

Stick

2,500 mm (Motorbazee); IndiaMART lists 2,980 mm

Track Gauge

Not publicly specified (standard track shoe width: 600 mm)

Track Length

Not publicly specified (51 shoes per side)

Handrail Height

Not publicly specified

Shipping Length

10,320 mm

Transport Width

3,190 mm (shipping width)

Ground Clearance

600 mm (per Machanx; verify, as this is high for a machine of this class)

Tail Swing Radius

Not publicly specified

Counterweight Clearance

Not publicly specified

Shipping Height Top Of Cab

3,185 mm (shipping height)

Length To Center Of Rollers

Not publicly specified

Main Pumps

Two variable-displacement piston pumps

Pilot Pump

Not publicly specified

Max Oil Flow

2 x 240 L/min; system pressure 34.3 / 37.3 MPa

Fuel Tank Capacity

540 L

Arm Length

2,500 mm (Motorbazee); IndiaMART lists 2,980 mm

Minimum Swing Radius

3,640 mm (minimum front swing radius)

Maximum Digging Depth

6,380 mm (Machinewale and Machanx); IndiaMART lists 6,915 mm

Maximum Digging Reach

Not publicly specified

Maximum Cutting Height

10,070 mm

Maximum Loading Height

7,025 mm (Motorbazee); other sources list 7,035 mm and 6,830 mm

Maximum Reach At Ground Level

Not publicly specified

Maximum Vertical Wall Digging Depth

Not publicly specified

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

Not publicly specified
