ACE AX-130

Model

KIRLOSKAR 4R1040T

Compliant

N/A

Gross Power

76 HP

Displacement

N/A

Maximum Torque

300 NM

Air Intake Type

N/A

Dump Angle

42 Degree

Dump Height

2780 MM

Max Pay Load

1850 Kg

Reach At Ground

1950 MM

Hinge Pin Height

N/A

Load Over Height

3250 MM

Rollback At Ground

40 Degree

Bucket Capacity Std

1 Cum

Bucket Breakout Force

N/A

Hinge Pin Forward Reach

N/A

Max Reach At Full Height

N/A

Maximum Lifting Capacity

N/A

Loader Arm Breakout Force

N/A

Below Ground Level Dig Depth

N/A

Max Reach At Full Height Bucket Dumped

0

Type

Hydrostatic steering for reliability and better control

System Pressure

N/A

Unit Displacement

N/A

Turning Circle Diameter Outside Bucket

N/A

Turning Circle Diameter Outside Bucket Not Braked

N/A

Max Dig Depth

4700 MM

Bucket Capacity

1 Cum

Bucket Rotation

185 Degree

Max Lift Capacity

N/A

Safe Working Load

N/A

Max Working Height

5290 MM

Dipper Configuration

N/A

Max Load Over Height

3620 MM

Bucket Breakout Force

N/A

Dipper Tear Out Force

N/A

Bucket Capacity Backhoe

0.2

Reach Ground Level To Swing Center

N/A

Reach At Full Height To Slew Center

N/A

Reach Ground Level To Rear Wheel Center

N/A

Wheelbase

2220 MM

Track Width Rear

1720 MM

Transport Length

N/A

Track Width Front

1840 MM

Width Over Bucket

2380 MM

Max Operating Weight

7500

Width Over Stabilizer

N/A

Height To Top Of Cabin

2900 MM

Minimum Ground Clearance

260 MM

Overall Transport Height

N/A

Pump Flow

N/A

Pump Type

N/A

System Type

N/A

System Relief Pressure

N/A

Coolant

water cooled

Fuel Tank

160 Ltr

Rear Axle

3 Ltr

Engine Oil

11 Ltr

Hydraulic Oil System

135 Ltr

Hydraulic Oil Replacement

N/A

Transmission Oil Capacitysystem

17 Ltr

Standard Tyre Rear

16.90 - 28 - 12 PR

Standard Tyre Front

9.00 x 16 – 16 PR

Hd Tyre Rear Optional

N/A

Parking

N/A

Service

N/A

Rear

Rigid axle with CARRARO planetary drive

Front

Drive & Steer Axle, centrally pivoted

Front Axle Oscillation

N/A
