HYUNDAI R130

Engine Power

94 HP (70.1 kW) gross @ 1,950 rpm

Bucket Capacity

0.65 m3 GP (SAE heaped) / 0.45 m3 HD

Operating Weight

12,100 kg

Make

Kirloskar (KOEL)

Type

Diesel, turbocharged

Model

4R1040T (a dealer listing shows 4R1040TJ)

Power

94 HP (70.1 kW) gross @ 1,950 rpm

Batteries

N/A - diesel machine; standard electrical system

Max Torque

36.5 kgf.m (about 357 Nm) @ 1,550 rpm

Weights Weight

12,100 kg

Weights Engine Oil

11.5 L (engine oil and filter)

Weights Final Drive

Not publicly specified

Weights Swing Drive

2.5 L

Weights Hydraulic Tank

100 L

Weights Operating Weight

12,100 kg

Weights Service Refill Capacities

Fuel tank 250 L; engine coolant 20 L; engine oil and filter 11.5 L; hydraulic tank 100 L; hydraulic system 180 L; swing device 2.5 L

Weights Hydraulic System Including Tank

180 L

Stick

1,960 mm (arm length)

Track Gauge

1,990 mm

Track Length

3,340 mm (overall crawler length)

Handrail Height

Not publicly specified

Shipping Length

7,240 mm (overall length, per dealer listing)

Transport Width

Not publicly specified (track shoe width: 500 mm)

Ground Clearance

440 mm

Tail Swing Radius

2,130 mm (per HD CE India page); one dealer lists a swing radius of 2,380 mm

Counterweight Clearance

Not publicly specified

Shipping Height Top Of Cab

2,800 mm (overall height, per dealer listing)

Length To Center Of Rollers

Not publicly specified (overall crawler length: 3,340 mm)

Main Pumps

2 variable-displacement piston pumps

Pilot Pump

Not publicly specified

Max Oil Flow

2 x 112 L/min; swing circuit 240 kg/cm2, travel circuit 330 kg/cm2

Fuel Tank Capacity

250 L

Arm Length

1,960 mm

Minimum Swing Radius

Not publicly specified

Maximum Digging Depth

4,770 mm

Maximum Digging Reach

7,460 mm (per dealer listing)

Maximum Cutting Height

Not publicly specified

Maximum Loading Height

5,540 mm (dumping height, per dealer listing)

Maximum Reach At Ground Level

7,320 mm (per HD CE India page)

Maximum Vertical Wall Digging Depth

4,070 mm (per dealer listing)

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

Not publicly specified
