CAT 320C Excavator

Bore

102 MM

Model

Cat 3066 T Diesel Engine

Power

144 HP

Stroke

130 MM

Displacement

6.37 Ltr

Power Iso 14396

0

Net Power Iso 9249

138 HP

Weights Engine Oil

30 Ltr

Weights Final Drive

10

Weights Swing Drive

8 Ltr

Weights Cooling System

30 Ltr

Weights Hydraulic Tank

120 Ltr

Weights Operating Weight

19700 Kg

Weights Fuel Tank Capacity

400 Ltr

Weights Service Refill Capacities

N/A

Weights Hydraulic System Including Tank

200 Ltr

Maximum Pressure Swing

25000 Kpa

Maximum Pressure Travel

34300 Kpa

Main System Maximum Flow

N/A

Maximum Pressure Equipment

N/A

Hydraulic System

N/A

Boom

N/A

Stick

N/A

Bucket Capacity

0.6

Lifting Capacity

N/A

Maximum Digging Depth

6620 MM

Maximum Cutting Height

N/A

Maximum Loading Height

N/A

Minimum Loading Height

N/A

Stick Digging Force Iso

N/A

Bucket Digging Force Iso

N/A

Maximum Reach At Ground Level

9760 mm

Maximum Vertical Wall Digging Depth

N/A

Maximum Depth Cut For 2440 Mm 8ft Level Bottom

N/A

Cylinder Bore

120 MM

Cylinder Store

1260 MM
